Introduction
What if your model could run twice as fast and use half the memory, without giving up much accuracy?
This is the promise of knowledge distillation: training smaller, faster models to mimic larger, high-performing ones. In this post, we’ll walk through how to distill a powerful ResNet50 model into a lightweight ResNet18 and demonstrate a +5% boost in accuracy compared to training the smaller model from scratch, all while cutting inference latency by over 50%.
You’ll learn:
- What knowledge distillation is and how it works
- Why it’s useful for deployment on resource-constrained devices
- How to implement it in PyTorch using both soft target alignment and intermediate feature matching
- How a distilled ResNet18 performs against a baseline trained from scratch
What Is Knowledge Distillation?
Knowledge distillation, first proposed by Hinton et al., is a technique designed to transfer the rich, nuanced information, often referred to as “dark knowledge”, from a large, high-capacity model (the teacher model) to a smaller, more efficient model (the student model). This process enables the student model to mimic the teacher’s behavior, capturing its insights and generalization capabilities while maintaining a significantly reduced size.
The key idea: rather than training the student only on ground-truth labels, we also train it to mimic the output distribution of the teacher model. These soft targets contain valuable information about class relationships that can help the student generalize better.
If the teacher and student architectures are compatible, the student model can be trained to mimic not only the teacher’s output distribution but also its intermediate feature representations from inner layers. By aligning the student’s internal feature maps with those of the teacher, this additional supervision enables the student to better capture the teacher’s reasoning process. The following code example demonstrates how to implement this approach effectively.
Why Use It?
- Reduce model size for mobile & embedded devices
- Achieve faster inference with smaller models
- Maintain much of the accuracy of larger models
- Leverage expensive pretrained models efficiently
How Does It Work?
The training loss for the student typically combines:
- Cross-entropy loss with the ground-truth labels (hard targets)
- KL divergence between the student and teacher soft logits (soft targets)
To understand the second part, let’s first recall how the softmax function works:
$$ P_i = \frac{e^{z_i}}{\sum_j e^{z_j}} $$
This turns the raw model logits into a probability distribution. In a well-trained model, this distribution is often very “peaked”, assigning high confidence to one class and nearly zero to others.
For example, regular softmax might output: [0.95, 0.02, 0.01, 0.01, 0.01]
These probabilities are not very informative beyond the top prediction.
Temperature Scaling
To soften this distribution and reveal more information about the model’s understanding of class relationships, we introduce a temperature parameter ( T > 1 ):
$$ P_i^{(T)} = \frac{e^{z_i / T}}{\sum_j e^{z_j / T}} $$
With a higher temperature:
- The probability distribution becomes more spread out
- We get outputs like:
[0.4, 0.2, 0.15, 0.15, 0.1] - The student learns not just the right answer, but how the teacher differentiates among all classes
This is the core of knowledge distillation: using these soft targets alongside the hard labels to teach a student network not just what to predict, but how to think like the teacher.
PyTorch Example: ResNet50 ➞ ResNet18 on CIFAR-10
In this section, we will take a large teacher model, specifically a ResNet50 pretrained on ImageNet1K and fine-tuned on CIFAR-10, and distill its knowledge into a smaller, more efficient ResNet18 model.
We will then evaluate and compare the teacher and student models in terms of accuracy, latency, and size. Additionally, we will assess the performance of the student model trained directly on CIFAR-10 without knowledge distillation, to highlight the benefits of this technique.
For a complete, self-contained Jupyter Notebook implementation, visit this link. It is part of my Neural Network Optimization GitHub repository.
Basic Setup
import os
import time
import torch
import torch.nn as nn
import torch.nn.functional as F
from torch.utils.data import random_split, DataLoader
from torch.optim.lr_scheduler import ReduceLROnPlateau
from torchvision import models
import torchvision.transforms as transforms
from torchvision.datasets import CIFAR10
print(f"PyTorch Version: {torch.__version__}")
device = torch.device("cuda" if torch.cuda.is_available() else "cpu")
print(f"Device used: {device.type}")
Load Dataset
Loads the CIFAR-10 data, prepare train / validation / test split and creates data loaders.
# define transform for CIFAR-10 dataset
transform = transforms.Compose([
transforms.ToTensor(),
transforms.Normalize(mean=[0.4914, 0.4822, 0.4465], # CIFAR-10 means
std=[0.2023, 0.1994, 0.2010])
])
# load full CIFAR-10 train set
full_trainset = CIFAR10(root='./data', train=True, download=True, transform=transform)
# calculate split sizes for train and validation sets
train_size = int(0.9 * len(full_trainset))
val_size = len(full_trainset) - train_size
# perform split
train_subset, val_subset = random_split(full_trainset, [train_size, val_size])
print(f"Train samples: {train_size}")
print(f"Validation samples: {val_size}")
# create DataLoaders
train_loader = DataLoader(train_subset, batch_size=128, shuffle=True)
val_loader = DataLoader(val_subset, batch_size=128, shuffle=False)
# CIFAR-10 test set and loader for accuracy evaluation
test_set = CIFAR10(root='./data', train=False, download=True, transform=transform)
test_loader = DataLoader(test_set, batch_size=128, shuffle=False)
print(f"Test samples: {len(test_set)}")
Output:
Train samples: 45000
Validation samples: 5000
Test samples: 10000
Define Models
In this example, we enhance the knowledge distillation process by training the student model to learn not only from the teacher model’s output distribution but also from its intermediate feature representations. Since ResNet50 and ResNet18 share a similar architecture, their intermediate features can be aligned for additional supervision. However, the number of channels in their feature maps differs. To address this, we introduce a 1x1 convolutional layer to project the teacher’s feature space into the student’s feature space, enabling effective feature matching between the two models.
def setup_models(device):
"""
Setup teacher and student wrapper
"""
# teacher: ResNet50 pretrained on ImageNet, re-headed for CIFAR-10
teacher = models.resnet50(weights=models.ResNet50_Weights.IMAGENET1K_V2)
teacher.fc = nn.Linear(2048, 10)
teacher = teacher.to(device)
# student: ResNet18 without pretrained weights
student = models.resnet18(weights=None)
student.fc = nn.Linear(512, 10)
student = student.to(device)
# define the intermediate feature channels for both teacher and student
student_channels = [64, 128, 256, 512]
teacher_channels = [256, 512, 1024, 2048]
# create projection layers to align teacher's feature maps with student's feature maps
proj_layers = [
FeatureProjector(in_c, out_c).to(device)
for in_c, out_c in zip(student_channels, teacher_channels)
]
# wrap the student model with the projection layers
student_wrapper = StudentWrapper(student, proj_layers).to(device)
return teacher, student_wrapper
class FeatureProjector(nn.Module):
"""
Feature projector to match student -> teacher feature shapes
"""
def __init__(self, in_channels, out_channels):
super().__init__()
# define a 1x1 convolutional layer to project feature maps
self.proj = nn.Conv2d(in_channels, out_channels, kernel_size=1)
def forward(self, x, target_shape):
# check if the spatial dimensions of the input match the target shape
if x.shape[2:] != target_shape[2:]:
# adjust spatial dimensions using adaptive average pooling
x = F.adaptive_avg_pool2d(x, output_size=target_shape[2:])
# apply the projection layer to transform feature maps
return self.proj(x)
class StudentWrapper(nn.Module):
"""
Wrapper for the student model with projection layers
"""
def __init__(self, student_model, proj_layers):
super().__init__()
# store student model
self.model = student_model
# store projection layers for feature alignment
self.projections = nn.ModuleList(proj_layers)
def forward(self, x):
# collect intermediate features from ResNet blocks
features = []
x = self.model.conv1(x)
x = self.model.bn1(x)
x = self.model.relu(x)
x = self.model.maxpool(x)
for i, block in enumerate([self.model.layer1, self.model.layer2, self.model.layer3, self.model.layer4]):
# pass through ResNet blocks
x = block(x)
# append features from each block
features.append(x)
# pool the final feature map and compute logits
pooled = F.adaptive_avg_pool2d(x, (1, 1))
flat = torch.flatten(pooled, 1)
logits = self.model.fc(flat)
return logits, features
def project_features(self, features, target_shapes):
"""
Project student features to match the shapes of teacher features.
"""
return [
proj(s_feat, t_shape)
for s_feat, t_shape, proj in zip(features, target_shapes, self.projections)
]
def extract_teacher_features(model, x, layers=[1, 2, 3, 4]):
"""
Extract teacher logits and intermediate features
"""
# collect intermediate features from ResNet blocks
features = []
x = model.conv1(x)
x = model.bn1(x)
x = model.relu(x)
x = model.maxpool(x)
for i, block in enumerate([model.layer1, model.layer2, model.layer3, model.layer4]):
x = block(x)
if (i + 1) in layers:
features.append(x)
# pool the final feature map and compute logits
pooled = F.adaptive_avg_pool2d(x, (1, 1)) # [B, C, 1, 1]
flat = torch.flatten(pooled, 1) # [B, C]
logits = model.fc(flat) # [B, 10]
return logits, features
# setup models
teacher, student_wrapper = setup_models(device)
Evaluation Functions for Size, Latency and Accuracy
def count_params(model):
"""
Function to count trainable parameters
"""
return sum(p.numel() for p in model.parameters() if p.requires_grad)
def measure_latency(model, input_size=(1, 3, 32, 32), device='cuda', repetitions=50):
"""
Function to measure average inference latency over multiple runs
"""
model.eval()
inputs = torch.randn(input_size).to(device)
with torch.no_grad():
# Warm-up
for _ in range(10):
_ = model(inputs)
# Measure
times = []
for _ in range(repetitions):
start = time.time()
_ = model(inputs)
end = time.time()
times.append(end - start)
return (sum(times) / repetitions) * 1000 # ms
def evaluate_accuracy(model, dataloader):
"""
Evaluate accuracy given model and loader
"""
model.eval()
model.to(device)
correct, total = 0, 0
with torch.no_grad():
for inputs, labels in dataloader:
inputs, labels = inputs.to(device), labels.to(device)
outputs = model(inputs)
preds = outputs.argmax(dim=1)
correct += (preds == labels).sum().item()
total += labels.size(0)
accuracy = correct / total
return accuracy
Fine-tuning the Teacher
Note: This fine-tuning is required only in this example since the ResNet50 network was pretrained on ImageNet1K and we need to replace its output layer to match to CIFAR-10.
def train_teacher(teacher, loader, epochs, tag, lr=1e-3, save_path="model.pth"):
"""
Trains a model with Adam and cross-entropy loss.
Loads from save_path if it exists.
"""
if os.path.exists(save_path):
print(f"Model already trained. Loading from {save_path}")
teacher.load_state_dict(torch.load(save_path))
return teacher
# no saved model found. training from given model state
optimizer = torch.optim.Adam(teacher.parameters(), lr=1e-3)
teacher.train()
for epoch in range(epochs):
for inputs, labels in loader:
inputs, labels = inputs.to(device), labels.to(device)
logits, _ = extract_teacher_features(teacher, inputs)
loss = F.cross_entropy(logits, labels)
optimizer.zero_grad()
loss.backward()
optimizer.step()
accuracy = evaluate_accuracy(teacher, val_loader)
print(f"({tag})\tEpoch {epoch+1}: loss={loss.item():.4f}, Accuracy (validation): {accuracy*100:.2f}%")
teacher.train()
if save_path:
torch.save(teacher.state_dict(), save_path)
print(f"Training complete. Model saved to {save_path}")
return teacher
# train the teacher on CIFAR-10
teacher = train_teacher(teacher, train_loader, epochs=25, tag="Fine-tuning teacher", save_path="tuned_pretrained_resnet50_on_CIFAR10.pth")
Output:
(Fine-tuning teacher) Epoch 1: loss=0.4818, Accuracy (validation): 81.60%
(Fine-tuning teacher) Epoch 2: loss=0.6269, Accuracy (validation): 81.70%
(Fine-tuning teacher) Epoch 3: loss=0.2588, Accuracy (validation): 82.72%
(Fine-tuning teacher) Epoch 4: loss=0.2500, Accuracy (validation): 82.88%
(Fine-tuning teacher) Epoch 5: loss=0.1956, Accuracy (validation): 83.52%
...
(Fine-tuning teacher) Epoch 25: loss=0.0483, Accuracy (validation): 84.14%
Training complete. Model saved to tuned_pretrained_resnet50_on_CIFAR10.pth
Training the Student via Distillation
The distillation loss is calculated with KL divergence on the student logits and teacher logits
def distillation_loss(student_logits, teacher_logits, targets, T=5.0, alpha=0.7):
"""
Combine soft and hard targets using KL divergence and cross-entropy
T = temperature, alpha = weighting between soft and hard losses
"""
# soft target loss (teacher softmax vs student softmax)
soft_targets = F.kl_div(
F.log_softmax(student_logits / T, dim=1),
F.softmax(teacher_logits / T, dim=1),
reduction='batchmean'
) * (T * T)
# hard label loss
hard_loss = F.cross_entropy(student_logits, targets)
return alpha * soft_targets + (1 - alpha) * hard_loss
def student_training_step(inputs, labels, teacher, student_wrapper, optimizer, device):
"""
Perform a single training step for the student model using knowledge distillation.
"""
inputs, labels = inputs.to(device), labels.to(device)
# extract teacher logits and intermediate features
with torch.no_grad():
teacher_logits, teacher_feats = extract_teacher_features(teacher, inputs)
# extract student logits and intermediate features
student_logits, student_feats = student_wrapper(inputs)
projected_feats = student_wrapper.project_features(student_feats, [t.shape for t in teacher_feats])
# calculate loss from features difference
feat_loss = sum(F.mse_loss(p, t.detach()) for p, t in zip(projected_feats, teacher_feats))
# calculate loss from output distribution, and include feature loss
loss = distillation_loss(student_logits, teacher_logits, labels) + 0.1 * feat_loss
# optimize with loss
optimizer.zero_grad()
loss.backward()
optimizer.step()
return loss.item()
def train_student(teacher, student_wrapper, dataloader, epochs, save_path="student_distilled.pth"):
"""
Trains a student model using knowledge distillation from a teacher model.
"""
# setup optimizer
optimizer = torch.optim.Adam(student_wrapper.parameters(), lr=1e-3)
# train the student using the teacher's output as soft targets
teacher.eval()
best_val_acc = 0.0
# reduce LR if validation loss doesn't improve for 3 epochs
scheduler = ReduceLROnPlateau(optimizer, mode='min', factor=0.5, patience=3)
for epoch in range(epochs):
student_wrapper.train()
running_loss = 0
for inputs, labels in dataloader:
loss = student_training_step(inputs, labels, teacher, student_wrapper, optimizer, device)
running_loss += loss
val_acc = evaluate_accuracy(student_wrapper.model, val_loader)
print(f"[(Training student)\tEpoch {epoch+1}] Loss = {running_loss/len(dataloader):.4f} | Val Acc = {val_acc*100:.2f}%")
scheduler.step(loss)
# save best checkpoint
if val_acc > best_val_acc:
best_val_acc = val_acc
torch.save(student_wrapper.state_dict(), save_path)
print("New best model saved.")
# load best checkpoint
student_wrapper.load_state_dict(torch.load(save_path))
student = student_wrapper.model
return student
# trigger student training
student = train_student(teacher, student_wrapper, train_loader, epochs = 25)
Output:
[(Training student) Epoch 1] Loss = 8.7847 | Val Acc = 60.02%
New best model saved.
[(Training student) Epoch 2] Loss = 5.9411 | Val Acc = 65.92%
New best model saved.
[(Training student) Epoch 3] Loss = 4.8069 | Val Acc = 69.38%
New best model saved.
[(Training student) Epoch 4] Loss = 4.0791 | Val Acc = 71.84%
New best model saved.
[(Training student) Epoch 5] Loss = 3.4702 | Val Acc = 74.46%
New best model saved.
...
[(Training student) Epoch 20] Loss = 0.3931 | Val Acc = 78.62%
Model Comparison Code
Finally we check the size of the teacher and student models, their latency and accuracy on test set.
# compare size, latency, and accuracy
teacher_params = count_params(teacher)
student_params = count_params(student)
teacher_latency = measure_latency(teacher, device=device)
student_latency = measure_latency(student, device=device)
teacher_acc = evaluate_accuracy(teacher, test_loader)
student_acc = evaluate_accuracy(student, test_loader)
print(f"Teacher Params: {teacher_params / 1e6:.2f}M")
print(f"Student Params: {student_params / 1e6:.2f}M")
print(f"Teacher Latency: {teacher_latency:.2f} ms")
print(f"Student Latency: {student_latency:.2f} ms")
print(f"Teacher Test Accuracy: {teacher_acc * 100:.2f}%")
print(f"Student Test Accuracy: {student_acc * 100:.2f}%")
Output:
Teacher Params: 23.53M
Student Params: 11.18M
Teacher Latency: 3.82 ms
Student Latency: 1.54 ms
Teacher Test Accuracy: 85.10%
Student Test Accuracy: 79.24%
Training a baseline student (ResNet18 from scratch)
Although the student model is half the size and 40% the latency of the teacher model, its accuracy dropped from 85.10% to 79.24%. To determine whether this is still a better approach compared to training the student model directly on the data, we trained another student model for the same number of epochs without using knowledge distillation. We refer to this model as the “baseline student”.
# define baseline student: ResNet18 training from scratch on its own, re-headed for CIFAR-10
baseline_student = models.resnet18(weights=None)
baseline_student.fc = nn.Linear(512, 10).to(device)
baseline_student = baseline_student.to(device)
# Train the baseline student on CIFAR-10
baseline_student = train_teacher(baseline_student, train_loader, epochs=25, tag="baseline-student", save_path="baseline_student.pth")
# Evaluate baseline student
baseline_student_acc = evaluate_accuracy(baseline_student, test_loader)
print(f"\nBaseline Student Test Accuracy: {baseline_student_acc * 100:.2f}%")
Output:
(baseline-student) Epoch 1: loss=1.0124, Accuracy (Epoch 1): 58.06%
(baseline-student) Epoch 2: loss=0.8091, Accuracy (Epoch 2): 63.10%
(baseline-student) Epoch 3: loss=0.8210, Accuracy (Epoch 3): 68.06%
(baseline-student) Epoch 4: loss=0.7438, Accuracy (Epoch 4): 68.74%
(baseline-student) Epoch 5: loss=0.8731, Accuracy (Epoch 5): 71.18%
...
(baseline-student) Epoch 25: loss=0.0202, Accuracy (Epoch 25): 74.10%
Training complete. Model saved to baseline_student.pth
Saved fine-tuned teacher.
Baseline Student Test Accuracy: 74.10%
Does Knowledge Distillation Help?
Training a baseline student model for the same number of epochs, without leveraging knowledge distillation, results in a test accuracy of 74.10%. In contrast, the distilled student achieves a significantly higher test accuracy of 79.24%. This represents a notable improvement of 5.14 percentage points, achieved without any increase in model size or latency.
This shows that while the student has lower capacity than the teacher, distillation helps it generalize better by learning not just from ground-truth labels, but also from the richer output distribution of the teacher. The teacher’s “dark knowledge” encodes class similarities and decision boundaries that the student wouldn’t otherwise see.
Even when both models are trained on the same data, distillation acts as a form of regularization, guiding the student with softer, more informative targets. This helps the student generalize better than it would by learning from hard labels alone, effectively helping a smaller model punch above its weight.
Model Comparison Table
| Model | Parameters | Latency (ms) | Accuracy (approx) | How it was trained? |
|---|---|---|---|---|
| ResNet50 (teacher) | 23.53M | 3.82 ms | 85.10% | Fine-tuned on CIFAR |
| ResNet18 (distilled student) | 11.18M | 1.54 ms | 79.24% | Knowledge distillation |
| ResNet18 (baseline student) | 11.18M | 1.54 ms | 74.10% | Trained directly |
Summary
- Knowledge distillation is an elegant technique to train smaller models with guidance from larger ones.
- The use of softened outputs via temperature scaling helps the student capture richer information.
- Internal representations can be leveraged to establish a stronger connection between the teacher and student models, potentially enhancing the student’s performance.
- This method works well in practice to compress models for deployment without drastically sacrificing performance.
